ADC 140 Curtain Track Rig-I-Flex® Series
Model 140 Rig-I-Flex® track is a versatile aluminum I-Beam style track system, ideal for curved or straight, medium weight curtains. It is suited for installations anywhere a curved system is desired. Track can be curved in the factory or on the job site, to a minimum radius of two feet.
- Medium duty I-beam.
- 11 gauge extruded aluminum.
- Mill finish or black anodized finish.
- Custom curvable at the factory or on site.
- Switchers available for complex configurations.
- Walk-along, cord driven, or motorized.
Ordering a track system for drapery or scenery may seem daunting, but we're here to help. Get great advice and pricing by submitting a request for a Custom Track System Quote online with your best guess on specs. Once your quote request is submitted, we'll contact you to guide you through the selection process. You can also contact us at 800-223-1624 or email. See more info below the products for sale on this page.
140 Series Rig-I-FlexCategory
Compare Products
You have no items to compare.
Showing 21-40 of 69
close
Splice Plate, 4224
Splicing bars for joining sections of Rig-I-Flex® 140 track . Comes in two halves.
Lap Clamp, 1407
Used to attach suspended, bi-parting track sections at the center overlap with proper spacing.
Lap Clamp for Continuous Curves, 1407-A
Used to attach curved, suspended, bi-parting track sections at the center overlap.
End Stop, 1309
Prevents Flex-I-Trac® 132 carriers from moving beyond center overlap and end of tracks.
Hanging Clamp / End Stop, 4208 / 4209
Used with Rig-I-Flex® 140 track. Use as a hanger or end stop.
Long Pocket Mounting Bracket, 1721
Long, 4", offset bracket for mounting Besteel® 170 track to side of ceiling pocket.
Short Pocket Mounting Bracket, 1722
Short, 2", offset bracket for mounting Besteel® 170 track to side of ceiling pocket.
Threaded Rod Adapter, 1408-A
This bracket connects to a hanging clamp and allows suspension of larger tracks.
4" Suspension Strap, 1478
Straight steel strap. Used to attach medium weight tracks to parallel pipe.
6" Suspension Strap with Clamp, 1478-A
Straight steel strap. Used to attach medium weight tracks to parallel pipe.
8" Suspension Strap with Clamp, 1478-AL
Straight steel strap. Used to attach medium weight tracks to parallel pipe.
4" Twist Strap, 1481
90º twisted steel strap. Used to attach medium weight tracks to perpendicular pipe.
6" Twist Strap with Clamp, 1481-A
90º twisted steel strap. Used to attach medium weight tracks to perpendicular pipe.
6" Twist Strap, 1481-L
90º twisted steel strap. Used to attach medium weight tracks to perpendicular pipe.
8" Twist Strap with Clamp, 1481-AL
90º twisted steel strap. Used to attach medium weight tracks to perpendicular pipe.
Pipe Clamp for 1" Pipe, 1713
Medium duty pipe clamp for 1" pipe. (1.315" OD) Requires hanging clamp. (not included.)
ADC 140 Track Additional Considerations
Model 140 track systems use idlers and spindles to guide the operating cord along the curved path of the track. Curved tracks require more force than straight tracks and so we recommend motorized operation of curved systems. For complex installations, multi-track switchers are available to route curtains into different configurations and locations, making this system well suited for television studios and production stages. Specifications, drawings, installation, and support documents can be found in the 140 Series Submital Binder and 140 Series Installation Instructions
