ADC Axis1 Controller
The Axis1™ Programmable Controller from ADC is the winner of the LDI award for best new product. It's the very heart of our Open Platform Automation™ product line. Given its open architecture, Axis1 can be used to control ADC ConTour Winches, our T-Lift 2.0 Curtain Lift System, and (amazingly) devices from other manufacturers. See the Read More link below to learn about the Axis1 ability to use a limitless variety of protocols and its unsurpassed Sil3 safety features.
Use the Axis1 Touch Controller on stage during tech or load-in for safe, line-of-sight setup. You can also use it as your main control desk during performance and events. For maximum sophistication, add an Art-Net lighting desk into the network for integrated cueing with lighting and projection.
Axis1 Controllers are available in handheld, rack mount or wall-mount configurations. og using on screen soft buttons, set limits, scaling, acceleration and deceleration ramps, timings and store up to 32 multi-axis groups. The Axis1 Touch model combines the ease of use of a handheld device with the sophistication of a cue/scene/group programming station.
Customizable layout, labels and color fills let you configure each screen exactly as you want. Access to the controller can be limited by login for administrators or users, and remote support login may be enabled for easy trouble-shooting.

The soul of the Axis1 Touch Controller is its Open Platform Automation technology. That's ADC’s innovative control system where ease-of-use is married with the highest possible safety standards. Using POE (power over ethernet), Axis1 achieves e-stop over virtual wire, eliminating the need for a secondary physical e-stop circuit. This Sil3 compliant e-stop functionality is available over the same Cat 6 Ethercon networking cable used for data control and can be distributed throughout your existing network architecture – a massive savings in time and money. Add additional Axis1E-Stop nodes anywhere you have a network jack.
The Axis1 Automation Platform is ready for Modbus control, Art-Net, or sACN and can be customized for use with a variety of additional protocols.
-
- 7" LCD capacitive touch screen
- Extruded aluminum case
- Hand held, rack mount, and wall mount options
- Integrated power and E-stop over cat 6 ethercon cable (e-stop over virtual wire)
- Single and multi-axis jog control
- Configuration wizard for setting scaling and axis control
- User defined axis naming and direction settings
- Edit position, speed, color, name for up to 32 multi axis scenes with variable speed and position
- Axis current monitoring and current limiting
- Remote drive programming and parameter editing
- Easy integration, testing and setup tools
- Grouping function to provide synchronization and position error
- USB Interface for remote Ethernet, Wi-Fi, keyboard, or user security interfaces
- Admin and user level controls
-
- Remote support / log in capabilities for updates, user training and troubleshooting
